Ecolux™ Low-E Window Film
Stay Cool & Go Green With Solar & Low-E Window Film
Keep the heat out in the summertime and lock it in during winter with Panorama Ecolux™ window films. Using advanced technology, this low-emissivity film helps you control the climate in your home or office while reducing energy bills.
Key Benefits:
- One of the most advanced solar and Low-E window films
- Spectral selectivity blocks 52% of solar energy
- Get the benefit of natural light in every room
- Protects against harmful UV damage
** Window Film Installers is proud to be part of the Panorama Elite Window Film Network, providing the Panorama window film range in New York.
| Specification | Ecolux 70 |
|---|---|
| Visible light transmittance % | 67% |
| Visible light reflectance (exterior) % | 13% |
| Visible light reflectance (interior) % | 4% |
| Solar heat gain coefficient | 0.47 |
| Total solar energy rejected % | 53% |
| UV Tdw-ISO @ 300 to 700 nm % | 40% |
| UV light blocked (300 to 380 nm) % | >99% |
| Fade reduction | 51% |
| Specification | |||
|---|---|---|---|
| Ecolux 70 | |||
| Visible light transmittance % | |||
| 67% | |||
| Visible light reflectance (exterior) % | |||
| 13% | |||
| Visible light reflectance (interior) % | |||
| 4% | |||
| Solar heat gain coefficient | |||
| 0.47 | |||
| Total solar energy rejected % | |||
| 53% | |||
| UV Tdw-ISO @ 300 to 700 nm % | |||
| 40% | |||
| UV light blocked (300 to 380 nm) % | |||
| >99% | |||
| Fade reduction | |||
| 51% | |||
Performance Notes:
- Performance results are calculated using the NFRC methodology and LBNL Window software, applied to 1/4″ (6mm) clear glass. These results are intended for estimation purposes only and may vary within industry standards. The data provided is for informational use and may reflect normal manufacturing variations.
- Glare and fade reduction performance results are determined by comparing filmed glass to untreated glazing.
CSI Specifications: Solar Control Films 08 87 13
Architectural Sample Pages
Architectural Warranties
Get in Touch with a Specialist in NYC
Stay Cool & Go Green With Solar & Low-E Window Film
Keep the heat out in the summertime and lock it in during winter with Panorama Ecolux™ window films. Using advanced technology, this low-emissivity film helps you control the climate in your home or office while reducing energy bills.
Key Benefits:
- One of the most advanced solar and Low-E window films
- Spectral selectivity blocks 52% of solar energy
- Get the benefit of natural light in every room
- Protects against harmful UV damage
** Window Film Installers is proud to be part of the Panorama Elite Window Film Network, providing the Panorama window film range in New York.
| Specification | Ecolux 70 |
|---|---|
| Visible light transmittance % | 67% |
| Visible light reflectance (exterior) % | 13% |
| Visible light reflectance (interior) % | 4% |
| Solar heat gain coefficient | 0.47 |
| Total solar energy rejected % | 53% |
| UV Tdw-ISO @ 300 to 700 nm % | 40% |
| UV light blocked (300 to 380 nm) % | >99% |
| Fade reduction | 51% |
| Specification | |||
|---|---|---|---|
| Ecolux 70 | |||
| Visible light transmittance % | |||
| 67% | |||
| Visible light reflectance (exterior) % | |||
| 13% | |||
| Visible light reflectance (interior) % | |||
| 4% | |||
| Solar heat gain coefficient | |||
| 0.47 | |||
| Total solar energy rejected % | |||
| 53% | |||
| UV Tdw-ISO @ 300 to 700 nm % | |||
| 40% | |||
| UV light blocked (300 to 380 nm) % | |||
| >99% | |||
| Fade reduction | |||
| 51% | |||
Performance Notes:
- Performance results are calculated using the NFRC methodology and LBNL Window software, applied to 1/4″ (6mm) clear glass. These results are intended for estimation purposes only and may vary within industry standards. The data provided is for informational use and may reflect normal manufacturing variations.
- Glare and fade reduction performance results are determined by comparing filmed glass to untreated glazing.
CSI Specifications: Solar Control Films 08 87 13
Architectural Sample Pages
Architectural Warranties
How Do I Request an Estimate?
For a quick and accurate online estimate, send pictures of your windows to [email protected]. Please include your building’s exact address in your email so we can check what type of windows you have via Google Street View, which helps us provide a more accurate quote.
